Sh-2 124 The Hidden NebulaSh-2 124 La Nebulosa Nascosta

Sh2-124, The Hidden Nebula, is a large emission nebula visible in the constellation Cygnus

in the north-west, along the Milky Way, east of the star pair ρ1 Cygni and ρ2 Cygni; the best period for its observation in the evening sky falls between July and December .

Sh2-124 is an extended nebular system, linked to the infrared source RAFGL 2789, which is identified with its stellar counterpart known as V645 Cygni, probably an O-class star or a Herbig Ae/Be star. The complex is probably located within Orion's Arm at a distance of about 2600 parsecs (about 8480 light years) although these data are discordant due to different estimates. If the distance of 2600 parsecs is correct, this nebula could be located in an inter-arm region or close to the inner edge of the Perseus Arm, in the foreground of the Cepheus OB1 association.The main stars responsible for the ionisation of the nebula's gas would be a blue star of spectral class O7V and a blue star of spectral class B2V, to which others could possibly be added. The nebula hosts star formation processes, and a number of infrared sources have been detected within it, five of which were identified by the IRAS satellite. Two masers were also detected, one with H2O emissions centred on the V645 Cygni component and one with CH3OH emissions.

Sh2-124, detta anche "La Nebulosa Nascosta", è una grande nebulosa a emissione visibile nella costellazione del Cigno

a nord-ovest, lungo la Via Lattea, a est della coppia di stelle ρ1 Cygni e ρ2 Cygni; il periodo migliore per la sua osservazione nel cielo serale va da luglio a dicembre.

Sh2-124 è un sistema nebulare esteso, legato alla sorgente infrarossa RAFGL 2789, identificata con la sua controparte stellare nota come V645 Cygni, probabilmente una stella di classe O o una stella Herbig Ae/Be. Il complesso si trova probabilmente all'interno del Braccio di Orione, a una distanza di circa 2600 parsec (circa 8480 anni luce), sebbene questi dati siano discordanti a causa di stime differenti. Se la distanza di 2600 parsec fosse corretta, questa nebulosa potrebbe trovarsi in una regione tra bracci o vicino al margine interno del Braccio di Perseo, in primo piano rispetto all'associazione Cepheus OB1. Le principali stelle responsabili della ionizzazione del gas della nebulosa sarebbero una stella blu di classe spettrale O7V e una stella blu di classe spettrale B2V, a cui se ne potrebbero aggiungere altre. La nebulosa ospita processi di formazione stellare, e al suo interno sono state rilevate diverse sorgenti infrarosse, cinque delle quali identificate dal satellite IRAS. Sono stati rilevati anche due maser, uno con emissioni di H2O centrate sulla componente V645 Cygni e uno con emissioni di CH3OH.

Equipment & Acquisition LogRegistro Attrezzatura e Acquisizione
Total integrationIntegrazione totale
22h 50m
TelescopeTelescopio
Tecnosky 90/540 FPL55 OWL
CameraCamera
QHYCCD QHY268 Pro M
MountMontatura
Sky-Watcher EQ6-R Pro
Guiding telescopeStrumento di guida
Sky-Watcher 70/500 Guidescope
Guiding cameraCamera di guida
ZWO ASI224MC
LocationLuogo
Vasto, Abruzzo, ItalyVasto, Abruzzo, Italia
HemisphereEmisfero
NorthernNord
Bortle scaleScala di Bortle
5
Celestial coordinatesCoordinate celesti
RA 21h 38m 41s · DEC +50° 18′ 25″
Pixel scaleCampionamento
1.14″/px
Field radiusRaggio del campo
88.1′
FiltersFiltri
Optolong H-Alpha 3nm 36 mmOptolong OIII 3nm 36 mmOptolong SII 3nm 36 mm
AccessoriesAccessori
QHYCCD QHYCFW3-M-USTecnosky TK_spian25var1x
SoftwareSoftware
Adobe PhotoshopOpen PHD Guiding Project PHD2Pleiades Astrophoto PixInsightStefan Berg Nighttime Imaging 'N' Astronomy (N.I.N.A. / NINA)The EQMOD Project EQASCOM

SESSION LOGREGISTRO SESSIONI

DateDataFilterFiltroFramesPoseExposureEsposizione
2023-07-09Optolong H-Alpha 3nm 36 mm62×600s10h 20m
2023-07-10Optolong SII 3nm 36 mm32×600s5h 20m
2023-08-11Optolong OIII 3nm 36 mm43×600s7h 10m
