M31 AndromedaM31 Andromeda

The Andromeda Galaxy is located in the constellation of the same name, approximately 2.5 million light-years from Earth. In very dark conditions, it is visible to the naked eye. With a disk diameter of 220,000 light-years and approximately 1 trillion stars—a population significantly greater than that of the Milky Way—it is the closest and most extensive spiral galaxy in the Local Group.

The system is moving toward the Milky Way at a speed of approximately 400,000 km/h; the gravitational interaction between the two galaxies will alter its structure in a collision expected in approximately 5 billion years.

The identification of Cepheid variable stars in photographic plates of the object, performed by Edwin Hubble, allowed the distance to be calculated. The measurement demonstrated that the structure—historically known as the Great Andromeda Nebula—was not an internal component of the Milky Way, but rather an independent galactic system.

La Galassia di Andromeda si trova nella costellazione omonima, a circa 2,5 milioni di anni luce dalla Terra. In condizioni di elevata oscurità, è visibile a occhio nudo. Con un diametro del disco di 220.000 anni luce e circa mille miliardi di stelle — una popolazione nettamente superiore a quella della Via Lattea —, costituisce la galassia a spirale più vicina e la più estesa del Gruppo Locale.

Il sistema si muove verso la Via Lattea a una velocità di circa 400.000 km/h; l'interazione gravitazionale tra le due galassie ne altererà la struttura in una collisione prevista tra circa 5 miliardi di anni.

L'individuazione delle stelle variabili Cefeidi nelle lastre fotografiche dell'oggetto, compiuta da Edwin Hubble, permise di calcolarne la distanza. La misura dimostrò che la struttura — storicamente nota come Grande Nebulosa di Andromeda — non era un componente interno alla Via Lattea, ma un sistema galattico autonomo.

Equipment & Acquisition LogRegistro Attrezzatura e Acquisizione
Total integrationIntegrazione totale
29h 55m
TelescopeTelescopio
Tecnosky 90/540 FPL55 OWL
CameraCamera
QHYCCD QHY268 Pro M
MountMontatura
Sky-Watcher EQ6-R Pro
Guiding telescopeStrumento di guida
Sky-Watcher 70/500 Guidescope
Guiding cameraCamera di guida
ZWO ASI224MC
LocationLuogo
Vasto, Abruzzo, ItalyVasto, Abruzzo, Italia
HemisphereEmisfero
NorthernNord
Bortle scaleScala di Bortle
5
Celestial coordinatesCoordinate celesti
RA 0h 43m 1s · DEC +41° 15′ 25″
Pixel scaleCampionamento
1.42″/px
Field radiusRaggio del campo
87.5′
FiltersFiltri
IDAS LPS-P2 36 mmOptolong Blue 36 mmOptolong Green 36 mmOptolong H-Alpha 3nm 36 mmOptolong Red 36 mm
AccessoriesAccessori
QHYCCD QHYCFW3-M-USTecnosky TK_spian25var1xZWO EAF
SoftwareSoftware
Adobe PhotoshopOpen PHD Guiding Project PHD2Pleiades Astrophoto PixInsightStefan Berg Nighttime Imaging 'N' Astronomy (N.I.N.A. / NINA)The EQMOD Project EQASCOM

SESSION LOGREGISTRO SESSIONI

DateDataFilterFiltroFramesPoseExposureEsposizione
2023-09-07IDAS LPS-P2 36 mm103×300s8h 35m
2023-09-08Optolong Red 36 mm52×300s4h 20m
2023-09-09Optolong Green 36 mm52×300s4h 20m
2023-09-10Optolong Blue 36 mm52×300s4h 20m
2023-09-11Optolong H-Alpha 3nm 36 mm50×600s8h 20m
